How I Built This Site: A Technical Deep Dive

TL;DR

Built a modern personal portfolio with Next.js 14, TypeScript, Supabase, and OpenAI. Features include AI-powered search, blog with MDX, rate-limited APIs, and 90% image optimization. Open source and production-ready.

Why I Built This

I needed a portfolio that showcased my work in AI and web development while also serving as a testing ground for new technologies. The site had to be:

Fast - Sub-2s load times
Smart - AI-powered features
Maintainable - TypeScript, good architecture
Engaging - Great UX, modern design

Architecture Overview

The Stack

Frontend:

Next.js 14 App Router - Server components, streaming, great DX
TypeScript (Strict Mode) - Zero 'any' types, maximum type safety
Tailwind CSS - Utility-first styling, dark mode built-in
Framer Motion - Smooth animations, page transitions

Backend:

Next.js API Routes - Serverless functions
Supabase - PostgreSQL database with vector search
OpenAI API - GPT-4 chat, embeddings for RAG
Resend - Transactional emails (contact form)

Infrastructure:

Vercel - Hosting, edge network, automatic deployments
GitHub - Version control, CI/CD

Why These Choices?

Next.js 14 over Gatsby/Astro:

Server Components for better performance
Streaming SSR for faster initial loads
Built-in API routes (no separate backend needed)
Great TypeScript support

Supabase over Firebase/MongoDB:

PostgreSQL (familiar, powerful)
pgvector extension for semantic search
Generous free tier
Open source

TypeScript Strict Mode:

Catches bugs at compile time
Better DX with autocomplete
Easier refactoring
Self-documenting code

Key Features & Implementation

1. AI-Powered Blog Search

The Problem: Users can't find relevant content easily.

The Solution: Retrieval-Augmented Generation (RAG) with semantic search.

How It Works:

// 1. Generate embeddings for all blog posts
const embedding = await openai.embeddings.create({
  model: "text-embedding-ada-002",
  input: blogContent,
});

// 2. Store in Supabase with pgvector
await supabase.from('embeddings').insert({
  content: blogContent,
  embedding: embedding.data[0].embedding,
  metadata: { title, url, date }
});

// 3. Search with semantic similarity
const { data } = await supabase.rpc('match_embeddings', {
  query_embedding: userQueryEmbedding,
  match_threshold: 0.78,
  match_count: 3
});

Result: Users find relevant posts even with vague queries. "AI stuff" returns RAG tutorials, prompt engineering guides, etc.

Performance:

Vector search: ~50ms average
Total API response: ~200ms

2. MDX Blog System

The Problem: Want rich content with React components, not just markdown.

The Solution: MDX with custom components.

Implementation:

// src/app/blog/[slug]/content.mdx
export const meta = {
  title: "My Post",
  description: "Description",
  date: "2025-01-19",
  image: "/images/blog/post.webp",
  tags: ["tag1", "tag2"]
};

## Your content here

<CustomComponent prop="value" />

Custom Components:

CodeBlock - Copy button, syntax highlighting
Newsletter CTA - Inline signup forms
Interactive Demos - Embedded visualizations

Benefits:

Write in Markdown (fast)
Use React when needed (flexible)
Type-safe meta exports
Auto-generated TOC

3. Performance Optimization

Image Optimization: Reduced total image size by 89.9% (23.7MB → 2.4MB)

Strategy:

# Convert to WebP, optimize quality
cwebp -q 85 -resize 1920 0 input.jpg -o output.webp

Results:

coachella.webp: 16MB → 840KB (94.8% reduction)
portrait.webp: 1.1MB → 124KB (88.7% reduction)
All images: ~90% average savings

Other Optimizations:

Code splitting - Dynamic imports for heavy components
Font optimization - Subset fonts, display=swap
Caching - Aggressive cache headers in middleware
Lazy loading - Images, ads, non-critical components

Final Metrics:

Lighthouse Score: 95+
First Contentful Paint: 1.2s
Time to Interactive: 2.1s

4. Rate Limiting System

The Problem: APIs are public, anyone can spam them.

The Solution: In-memory rate limiter with configurable limits.

// src/lib/rate-limit.ts
export const RATE_LIMITS = {
  AI_HEAVY: { requests: 5, window: 60 * 1000 },      // 5 req/min
  NEWSLETTER: { requests: 3, window: 5 * 60 * 1000 }, // 3 req/5min
  PUBLIC: { requests: 100, window: 60 * 1000 },       // 100 req/min
};

// Usage
export const POST = withRateLimit(handler, RATE_LIMITS.AI_HEAVY);

Protected Routes:

AI endpoints (chat, search) - 5 req/min
Newsletter APIs - 3 req/5min
Contact form - 3 req/5min

Why In-Memory?

Simple, no external dependencies
Fast (microsecond lookups)
Good enough for personal site
Can migrate to Redis later if needed

5. Type Safety (100%)

Challenge: Eliminate all TypeScript 'any' types.

Before: 16 violations After: 0 violations

Hardest Cases:

// ❌ Before - loses type safety
window.adsbygoogle = window.adsbygoogle || [];

// ✅ After - fully typed
interface AdSenseConfig {
  google_ad_client?: string;
  enable_page_level_ads?: boolean;
  [key: string]: unknown;
}

declare global {
  interface Window {
    adsbygoogle: AdSenseConfig[];
  }
}

Benefits:

Caught 12+ bugs at compile time
Better autocomplete in IDE
Safer refactoring
Self-documenting code

Project Structure

lscaturchio.xyz/
├── src/
│   ├── app/                    # Next.js App Router
│   │   ├── blog/              # Blog posts (MDX)
│   │   ├── api/               # API routes
│   │   └── [pages]/           # Other pages
│   ├── components/
│   │   ├── blog/              # Blog-specific
│   │   ├── ui/                # Reusable UI
│   │   └── [feature]/         # Feature components
│   ├── lib/                   # Utilities
│   │   ├── embeddings.ts      # Vector search
│   │   ├── rate-limit.ts      # Rate limiting
│   │   └── getAllBlogs.ts     # Blog data
│   ├── constants/             # Static data
│   └── types/                 # TypeScript types
├── public/
│   └── images/                # Optimized WebP images
└── scripts/                   # Build scripts

Key Patterns:

Server Components by Default - Only use 'use client' when necessary
Colocation - Components near their usage
Barrel Exports - Clean imports
Type-First - Define types before implementation

Lessons Learned

What Went Well

Next.js 14 App Router - Amazing DX, great performance
TypeScript Strict Mode - Caught so many bugs early
Supabase pgvector - Vector search is surprisingly easy
Image Optimization - 90% savings with minimal effort

What I'd Change

Start with Rate Limiting - Added it too late, almost got abused
More Tests - Built features fast, testing came later
Better Error Boundaries - Some crashes still slip through
Documentation as I Go - Had to backfill a lot

Unexpected Challenges

MDX TypeScript Integration - Meta imports don't work, had to duplicate
Search Params in Server Components - Needed Suspense boundaries everywhere
Dark Mode Flash - Had to use theme-provider with storage
Vercel Build Timeouts - Image optimization took too long initially

Performance Breakdown

Build Time

Development: ~3s cold start, ~200ms hot reload
Production: ~45s full build (49 pages)
Sitemap generation: ~1s

Runtime Performance

Homepage: 1.2s FCP, 2.1s TTI
Blog Post: 1.4s FCP, 2.3s TTI
Search: ~200ms API response

Bundle Size

First Load JS: 86.5 kB (excellent!)
Page-specific: 1-4 kB average
Shared chunks: Optimized with Webpack config

Open Source & Transparency

GitHub: github.com/lscaturchio/lscaturchio.xyz

What's Public:

✅ Full source code
✅ Commit history
✅ Architecture docs
✅ Build scripts

What's Private:

🔒 API keys (in .env.local)
🔒 Analytics data
🔒 Newsletter subscribers

License: MIT - Feel free to fork and adapt!

Tech Stack Deep Dive

Next.js 14 Configuration

Key Settings:

// next.config.mjs
export default {
  experimental: {
    optimizeCss: true,           // Faster CSS
    scrollRestoration: true,     // Better UX
  },
  webpack: (config) => {
    config.optimization.splitChunks = {
      chunks: 'all',
      maxInitialRequests: 25,    // More granular splitting
    };
    return config;
  },
};

Supabase Setup

Tables:

embeddings - Vector search (1536-dim, OpenAI ada-002)
newsletter_subscribers - Email list with unsubscribe tokens
views (planned) - Page view tracking

RPC Functions:

match_embeddings(query_embedding, threshold, count) - Semantic search
count_active_subscribers() - Newsletter stats

API Route Patterns

// Standard pattern for all routes
import { withRateLimit } from '@/lib/with-rate-limit';
import { RATE_LIMITS } from '@/lib/rate-limit';

async function handler(req: NextRequest) {
  // Validation
  if (!req.body) return NextResponse.json({ error: "..." }, { status: 400 });

  // Logic
  const result = await doSomething();

  // Response
  return NextResponse.json({ data: result });
}

export const POST = withRateLimit(handler, RATE_LIMITS.STANDARD);

Future Improvements

Short Term (Next Month)

View counter for blog posts
Blog reactions (like/bookmark)
Blog series/collections
Updated dates on old posts

Medium Term (Next Quarter)

Interactive code playgrounds
Course platform
Guest posts section
Analytics dashboard

Long Term (Someday)

Multi-language support
Mobile app (React Native)
Paid courses/content
Community features

Resources & Credits

Inspiration:

Lee Robinson's site - Performance tips
Josh Comeau's blog - Interactive demos
Derek Sivers - Simplicity in design

Tools:

Next.js Docs - Comprehensive guides
Supabase Docs - Vector search setup
Tailwind UI - Component patterns

Libraries:

Framer Motion - Animations
Lucide Icons - Beautiful icons
Rehype - MDX processing

Conclusion

Building this site was a journey of constant iteration and improvement. Started with a broken build (14+ errors), ended with a production-ready platform with 100% type safety and 90% image optimization.

Key Takeaways:

Start Simple - Ship fast, optimize later
Measure Everything - Can't improve what you don't measure
Type Safety Matters - Strict TypeScript saves time long-term
Performance Is UX - Fast sites feel better

The site is live, open source, and constantly evolving. If you have questions or want to collaborate, get in touch!

Want to build something similar? Fork the repo, follow this guide, and ship your own site in a weekend. Questions? Drop a comment below or reach out on Twitter.
